OSE-2800 OCT Optical Coherence Tomography

Model: OSE-2800
Quantity:

Trusted Services: 1. Video chat to check our factory and products; 2. Free online technical support and training; 3. Free online installation support; 4. 1-3 Years quality warranty; 5. Lifetime after sales support.

Send Inquiry

Chat on WhatsApp: +8613618377608

OSE-2800 OCT Optical Coherence Tomography

OSE-2800 OCT Optical Coherence Tomography

OSE-2800 OCT Optical Coherence Tomography

OSE-2800 OCT Optical Coherence Tomography

OSE-2800 OCT Optical Coherence Tomography

OSE-2800 OCT Optical Coherence Tomography

OSE-2800 OCT Optical Coherence Tomography

Specifications:

OCT IMAGING

Methodology

Spectral domain  OCT

Optical  Source

840nm  (Light Center Wavelength)

Axial Resolution  (optical)

5 microns (optical), 2.7  microns   (digital)

Transverse Resolution

15 microns (optical), 3 microns (digital)

A-scan Depth

3.0 mm

Diopter Range

– 20 to 20 diopters

Scan Patterns

Macula: HD line scan (6 mm or 12 mm), 3D scan (6 mm x 6 mm), 6-line radial scan, Multi (X-Y: 5 *5) Disc: 3Dscan (6 mm x 6 mm)

Anterior:HD line scan (6 mm), 6-line radial scan

Fundus Imaging

Minimum Pupil Diameter

3.0mm

Field of view

40 * 30

Soft Analysis

Macula

Retina thickness analysis; 3D view; En-face analysis; Progression analysis; EDI  function

Glaucoma

RNFL analysis; Ganglion cell analysis; Cup-disk analysis, Progression analysis; OU comparative analysis

Anterior  Segment

Manual measurement; Corneal thickness analysis; Epithelial thinckness analysis

Others

DICOM conformance;  Remote viewer software available

Weight

28.8kg

Dimension

532 mm (L) x 360 mm (W))x 540 mm (H)

Source voltage

AC 100 – 240 V

Frequency

50HZ 60HZ

Power Input

180VA
